Type and Description

Standard of Product

Plain annealed copper conductors, 2 cores PVC insulated laid parallel and separated by a bare copper Earth
continuity conductor/PVC sheathed flat. 300/500 volts grade to BS6004.

Conductor stranding: Class 1 - circular solid.
Class 2 - stranded circular or circular compacted.

Operating temperature: Maximum 70°C, Minimum bending 0 °C.

Minimum bending radius: (Based upon the larger dimension).Diameter up to 10mm 3 x overall diameter.Diameter 10m to 25mm 4 x overall diameter.

Conductor identification: Red, Black and Bare (earth)
